1. Features
- High accuracy within ±0.2 % of reading
- Compact size and light weight
- A fuel cooling function is provided as standard.
- Simultaneous measurement of temperature and pressure together with the flow rate
2.Flexible modification for construction machinery.
By making inlet filter larger,
supporting DC 24V or DC12V battery power supply and being reinforced with rubber feet,
on-board measurement of construction machinery and agricultural machinery is available.
3. Industry examples
We have introduction results in various industries. Please feel free to contact us if you have any desired specifications such as changing the flow rate range.
Railroad
Truck
Construction machine, farm machine
Industrial vehicle
* It is a fuel consumption detector for general diesel engines (self-sucking type by injection pump).
* It cannot use for vehicles equipped with a fuel feed pump to the engine the fuel tank.
* Please be careful when using the fuel injection system for an engine with a large fuel circulation flow rate. Please check with us before use.
* If the return fuel from the engine is 80 °C or higher, cool the fuel down by using a heat exchanger.
