Overview
Various types of test system as follows can be built up in combination with measurement control equipment and peripheral instruments (fuel flow meters, actuators, temperature control device, combustion analysis system, ECU monitor, OBD, sound and vibration measurement instruments, emission analyzer, smoke meter etc.)
·Traveling fuel economy test
·Gas emission test
·Output performance test
·Deterioration/endurance test
·Combustion analysis
·Sound source probing
Measurement system
System configuration
| Model name | Product name | Remarks | |
|---|---|---|---|
| 1 |
( Flexible Automatic Measuring System-release 5) |
Measurement and control board | |
| 2 | Bench test support application | Bench test support application for FAMS-R5 | |
| 3 | TC series | Throttle controller | |
| 4 | - | Fuel flow meter | |
| 5 | TQ-2000 | High-stiffness Torque Detector | |
| 6 | TQ-5300 | Torque Meter | |
| 7 | OS-2000 series | Time-series Data Analysis software (Transient analysis tool for vehicle test) |
|
| 8 | OC-1300 series | Multi-function Graph Creating software |
Related products
| Model name | Product name | Remarks | |
|---|---|---|---|
| 1 | DS-3284 | Combustion Analysis system | |
| 2 | - | Sound & Vibration measurement system |
Revised:2018/3/31
