Detection of rotational speed from rotational shaft
rotation A-4-4
Measuring the rotational speed at low-speed
The TM-3110 indicates rotational speed or shaft speed with 0000.0 and 000.00 by attaching rotary encoder to a roll shaft of conveyer.
Measurement range : approx. 0.1 r/min to 5,000 r/min
The price for coupling to fit with connection shaft needs to be quoted separately.
We have several types of rotary encoder to meet various requirements.
Model
Product name
1
TM-3110
Digital Tachometer
2
RP-432Z
Rotary encoder (compact multi-use type)
3
RP-0169
Signal cable for the RP-432Z ( 5 meter )
4
Coupling
Option or user preparation
Product Brochures (PDF)
Outer Dimensions (PDF)
