No load non-contact measurement by Laser

rotation F-1-4

Measurement of Velocity and Length of Wire/Wire Rod

You can measure the objects such as wire rods, which cannot be measured by contact method like sensor attachment or marking.
Spot diameter of the laser: an ellipse of 2 mm × 1 mm *If you would like to measure thin objects less than the spot diameter, please consult us.

Measurement range: 0 to ± 1,800 m / min
Measurement range: 0 to ± 3,600 m / min (with LV - 0730 installed)

System configuration

	Model name	Product name	Remarks
1	LV-7220	Laser Doppler Surface Velocity Meter Controller	Detection speed range：0 to ±1800 m/min
2	LV-7002	Laser Doppler Surface Velocity Sensor	Center of detection distance : 200 mm (from the bottom end of the sensor)
