Encoder Application

Rotary Encoder Measurement of length
Encoder A-1-3 Measuring length of rail



  • Press the RP-732-300P/R Roller encoder to the rail and the length of the rail can be measured.
  • Pulse output can be converted to length using pulse count function of the RV-3150 Reversible counter. The measured value can be displayed on a large-sized external


  Model Product name Remarks
1 RP-7400-200P/R Roller encoder For line speed measurement. output pulse: 300 P/R, can be measured every 1 mm/pulse. With wide roller
2 RV-3150 Reversible counter Major function: Multiplier selection, ratio setting function, offset, decimal point position selection, counting selection, comparator output, analog output, BCD output, RS-232C interface
3 RP-0182 Signal cable RP-7400←→RV-3150 5 m (one end open)
