Applicable Engine Type |
Gasoline engine (*1) |
|
2-cycle |
1, 2, 3, 4-cylinder |
|
4-cycle |
1, 2, 3, 4, 6, 8-cylinder |
|
Detection Method |
Electromagnetic induction method |
|
Detecting Object |
Ignition leakage magnetic flux |
|
Detection Distance |
10 to 200mm |
|
Applicable Standard Sensor |
IP-2800 Ignition Detector (suction
cup type) |
|
Applicable External Sensor |
VP-201 Engine Revolution Detector
(option, for diesel engine) |
|
Measurement range |
4-cycle |
2-cycle |
Measurement Range |
|
1-cylinder |
|
120 to 20,000 r/min |
2.00 to 333.33 r/s |
|
2-cylinder |
1-cylinder |
120 to 20,000 r/min |
2.00 to 333.33 r/s |
|
3-cylinder |
|
120 to 20,000 r/min |
2.00 to 333.33 r/s |
|
4-cylinder |
2-cylinder |
120 to 20,000 r/min |
2.00 to 333.33 r/s |
|
5-cylinder |
|
120 to 20,000 r/min |
2.00 to 333.33 r/s |
|
6-cylinder |
3-cylinder |
120 to 15,000 r/min |
2.00 to 250.00 r/s |
|
8-cylinder |
4-cylinder |
120 to 12,000 r/min |
2.00 to 200.00 r/s |
| Measurement accuracy |
±1
r/min (±2 r/min for speed above 10,000
r/min)
±0.02 r/s
(±0.04 r/min for
speed above 166,66 r/s) |
|
Display type |
LCD, 5-digit |
|
Measurement Display Time |
1s, automatically repeated |
|
OVER Display |
"OVER" mark is appeared when the
display is 20,000 r/min or 333.33 r/s. |
|
Low Battery Display |
When the battery voltage drops
below 3.3V, "Batt" mark appears on the display. |
|
Power/Battery life |
3 type AA batteries
approx. 20 hrs when backlighting used (approx. 150 hrs without
use of backlighting)
AC adaptor (option) |
|
Operating Temperature Range |
0 to +40°C |
|
Storage Temperature Range |
-10 to +55°C |
|
Outer dimensions |
160(L) x
36(H) x 60(D) mm |
|
Weight |
approx. 190g
(including batteries) |
