Torque Meter          Quality inspection

A-2-5       Measuring torque characteristic of DC motor



  • This example shows how to measure and display as graphs the characteristics of DC motor of torque, rotational speed, current, voltage. The efficiency performed by internal calculation also can be displayed.
  • The DC voltage/current detector (Made to order) is required to use in combination with the MT-84T13.

Product list

  Model Product name Remarks Qty
1 TS-8700 Torque Station Pro.   1
2 MT-84T13 Torque detector equipped with a hysteresis brake   1
3 /B1 XYZ base for small capacity   1
4 /X1 XYZ stage for small capacity(equivalent to MT-0094)   1
5 /V1 V block A for small capacity   1
6 MT-0113 Torque calibrator for MT type torque detector   1
