Dimensional inspection and screening of parts
dimension A-2-3
Measurement of unevenness and screening of metallic parts
This example shows how to measure the unevenness of surface at the two points of micro-part.
When the distance between two points is short, pen-shaped linear gauge sensor is optimal in order to measure the unevenness of surface.
The pen-shaped linear gauge sensor, the GS-7000 series enables to obtain resolution at 0.5μm.
Model
Product name
1
GS-7710
Linear gauge sensor
2
DG-2310
Digital gauge counter
3
AA-8103
BCD cable (3 meter)
4
AA-8107
BCD cable (3 meter)
5
AX-5022A
RS232C cable (2 meter)
6
RQ-1410
Digital printer
