| Measurement items |
Thickness, gaps, difference, user-defined
calculation results |
| Display |
320 x 240 dot matrix LCD, with backlight |
| Display modes |
Absolute value, deviation, max., min. |
| Resolution |
Depending on VE series gap detectors to be combined
(0.1 ㎛ or 1㎛) |
| Parameter settings |
by key operation on the panel
can be stored in the internal memory and held in the power-off memory |
| Sampling time |
20 ms and 89 ms, selectable |
| Averaging |
2 to 32 times (moving averaging) |
| Real-time data processing |
Max. & min. values of measuring data are displayed
in real time |
| Data memory |
Storage capacity : 2048 samples |
| Comparator function |
2 channels (independent)
Output : open no-voltage contacts |
| Interface |
BCD |
5-digit BCD data output |
| RS-232C |
displayed data and panel conditions |
| SYNC |
Input/output of clock for sampling in parallel
operation of multiple CL-6200s. |
| AUX IN (opt) |
Auxiliary analog input : -5 to +5V |
| GP-IB (opt) |
displayed data and panel conditions (compliant with
IEEE-488) |
| Output |
analog |
-5 to +5V, 2 channels |
| printer |
Measured data is printed out (compliant with
Centronics) |
| external control |
Using external contact signals for
START/STOP, PAUSE, STORE, PRINT
Input format : no-voltage contact input |
| Operating temperature |
0 to +40 °C
+18 to +28 °C (guaranteed accuracy range) |
| Humidity |
20 to 80% R.H * with no condensation |
| Power supply |
100 to 240 VAC, 50/60 Hz, 60VA or less |
| Outer dimensions |
315 (W) x 150 (H) x 345 (D) mm |
| Weight |
Approx. 6 kg |
