A-1-1 Torque (energy efficiency) measurement of blades for wind power generator
- In this application, rotational power (torque) enables the measurement and monitoring of energy efficiency, which varies with angle or material of blades for wind power generator.
- The TQ-5300 torque meter can be connected to a PC via the TQ-0532 RS-232C interface option to save result data and configure settings. In addition to RS-232C, EtherCAT and CAN are also available.
Product list
| Model | Product name | Remarks | Qty | |||
|---|---|---|---|---|---|---|
| 1 | TQ-3507 | Flange type High-stiffness Torque detector | 1 | |||
| 2 | TQ-0235 | Rotational detection gear (180 P/R) | 1 | |||
| 3 | MP-9830 | Magneto-electric rotational detector | 1 | |||
| 4 | TQ-5300 | Torque Meter | 1 | |||
| 5 | TQ-0532 | RS-232C communication function | 1 | |||
| 6 | MX-8130 | Signal cable (30 m) | 1 | |||
| 7 | TQ-0130 | Torque cable (30 m) | 1 | |||
|
||||||
